Model S-100/60

Max.grinding length 1000 mm.
Max. grinding width 750 mm.
Distance from the table to the center of the wheel 650 mm.
Max. allowed piece 1000 Kgs.
Longitudinal travel 1160 mm.
Cross travel 650 mm.
Wheel dimensions 400x100x127 mm.
Wheel speed 1500 r.p.m.
Total power 16 Kw.
Dimensions 4600x2700x2600 mm.
Weight 7.300 Kgs.

Equipped with:

  • CN FAGOR in 2-axis
  • Magnetic chuck of 1000×600 mm.
  • Cooling filter with paper roll.
  • Hydraulic diamond wheel
Machine available, subject to prior sale.
The data without the obligation, may be changed without notice.


Type: Grinders

Make: GER

Model: S-100/60
