Ref: 161/M075

Rectificadora TOS – 161/M075

  • Used Machinery, Grinding Machines
5000 mm.Distance between points
60 mm.Diámetro mínimo a rectificar
1000 mm.Diámetro máximo a rectificar
100.Cono del husillo métrico
Distance between points
5000 mm.
Diámetro sobre bancada 1000 mm., con lunetas tipo CARDAN :
1500 mm.
Diámetro sobre bancada utilizando piedra
Ø 660 mm 1000
Diámetro sobre bancada utilizando piedra
Ø 750 mm 850
Diámetro mínimo a rectificar
60 mm.
Diámetro máximo a rectificar
1000 mm.
Diámetro sobre la bancada en el apoyo grande
500 – 650 mm.
Diámetro sobre la bancada en el apoyo pequeño
150 – 350 mm
Cono del husillo métrico
100
Cono en el manguito de la contrapunta métrico
100.
Largo máximo del rectificado cóncavo y convexo
4000 mm.
Revoluciones del objeto rectificado
1 min 5 – 50 r.p.m
Cono del husillo porta-piedra
1:5 Métrico 110
Revoluciones del husillo porta-piedra
1 min 435-1330 r.p.m.
Movimiento transversal del husillo porta-piedra
325 mm.
Velocidad de la traslación hidráulica del cabezal porta-piedra
0.75 m/min.
Velocidad longitudinal del carro, con regulación continua
0.055 – 1.15 m
Movimiento transversal del cabezal porta-piedra durante el avance automático
Ø 0.0 -2 mm.
Concavidad y convexidad de los cilindros
Ø 2 mm.
Peso máx. admisible
12.000 kgs.
Dimensiones
13500 x 4700 mm
Peso máquina
40.000 kgs
Retrofitada al completo en el
2006.
Equipped with:
Muelas.
2 juegos de lunetas de Ø 500 mm
2 juegos de lunetas de Ø 50 mm
1 juego de lunetas de Ø 200 mm
Diversas herramientas y accesorios.

¿Necesita más información sobre esta rectificadora TOS BEV-100 de segunda mano?

Contact us and we will inform you without any type of commitment about this rectificadora TOS. In addition, if you wish, you can also visit our facilities located in Parets del Vallés (Barcelona). We have all types of new and used industrial machinery: conventional milling machines, CNC milling machines, conventional lathes, CNC lathes, machining centers, etc.

You can contact us through:

cecamasa@cecamasa.com
+34 935 730 225

Machine available, subject to the right of sale.
The data is not binding and may be modified without prior notice.

Price to consult

VAT not included · Transport to be negotiated
