Ref: 218-B004

Torno GEMINIS GHT9 G2 1600×6000

  • Used Machinery, CNC lathes

· Year 2011

6000 mmDistance between points
4Gama velocidades
0-90 rpmGama I de velocidad
0-180 rpmGama II de velocidad
Distance between points:
6000 mm
Altura de centros:
800 mm
Ø on bench:
1600 mm
Ø About car:
1110 mm
Ø main shaft hole:
150 mm
Speed ​​range:
4
Gama I de velocidad:
0-90 rpm
Gama II de velocidad:
0-180 rpm
Gama III de velocidad:
0-355 rpm
Gama IV de velocidad:
0-710 rpm
Recorrido del carro transversal:
830 mm
Ø caña:
240 mm
Rod course:
270 mm
Peso máx. entre puntos
20 ton
Peso máx. admitido con las dos lunetas (entre 4 y 5 ton cada una)
30 ton
Potencia total instalada
100 kW
Dimensiones y peso de la máquina:
10.150 x 2.550 mm 30 ton
Equipped with:
Control:
Siemens Sinumerik 840 D Shop Turn
Plato 4 garras independientes:
Ø 1400 mm
Plato 4 garras independientes:
Ø 560 mm
Torreta automática cuadrada:
SAUTER 4 pos - ز 450x450 mm
Tailstock and reed:
motorized
Chip extractor:
Yeah
1 luneta:
Ø 100-500 mm
1 luneta:
Ø 500-900 mm

Complete technical sheet (PDF)

Torno GEMINIS GHT9 G2 1600×6000

Datos de este torno CNC GHT9 G2 de ocasión

Descubre este torno CNC GEMINIS GHT9 G2 de segunda mano, equipado con el control Siemens Sinumerik 840 D Shop Turn. ideal para aplicaciones de mecanizado de precisión. ¡Disponible para entrega inmediata en nuestras instalaciones!

¿Necesita más información sobre este torno cnc GHT9 G2 1600×6000 de segunda mano?

Contact us and we will inform you without any type of commitment about this twin cnc lathe. If you wish, you can also visit our facilities located in Parets del Vallés (Barcelona), where we have all types of new and used industrial machinery: conventional milling machines, CNC milling machines, conventional lathes, grinding machines, etc. You can contact us through: cecamasa@cecamasa.com +34 935 730 225

Price to consult

VAT not included · Transport to be negotiated

Request information and price
direct WhatsApp
+34 935 730 225

Key data

Type: CNC lathe

Mark: twins

Model: GHT9 G2 1600×6000

Year of manufacture: 2011

Reference: 218-B004

Request information

Guaranteed response the same day.

Machine: Torno GEMINIS GHT9 G2 1600×6000

No obligation · Protected data
